Water-Cooled Packages (WCP)

Perfect for users with continuous, 24/7 demands, MAKO's water-cooled high-performance compressors are designed for simplified maintenance and quick remove/replace valves. Available in 40 HP and 75 HP options, these compressors come with a heavy-duty skid, ODP motor, motor starter, and a built-in compressor cooling system for enhanced efficiency.

Standard Installed Features:

• V-Belt Drive with Guard
• Low Oil Pressure Switch (Pressure Lubricated Units Only)
• NEMA Design ODP Motor (Non CE Marked)
• Gauge Panel
• Hour Meter
• Emergency Stop Button
• Auto Start/Stop Air Pressure Switch
• High Air Temperature Switch
• Starter
• Control Transformer
• Auto Condensate Drain System
• Auto Drain Muffler/Reservoir (Loose Accessory)
• Visual CO/Moisture Indicator Siteglass
• Closed Loop Cooling System
• Inlet Filter
• Intercooler & Aftercooler
• Interstage & Final Stage Relief Valves
• Condensate Separator
• Flywheel

These compressors are tested and certified to meet the US Navy's NAVSEA stringent requirements, ensuring reliability and performance.
